肉條機機產品簡介

Introduction meat machine products

一、用途：

A, use:

肉條機是本公司應用最先進技術研制成功的新型食品機械， 本機專業切制各種肉類，切成條、丁狀，如：五花肉、牛肉等。

Strips of machine is the company using the most advanced technology to develop a new food machinery professional success, the machine cutting all kinds of meat, cut into strips, cubes, such as: pork, beef etc..

二、特點：

Two, characteristics:

①該機外形美觀，結構緊湊、操作簡便、工作可靠、功能齊全，維修方便、適應性強，既可單機生產也適用于大型肉類加工流水線。

This machine has the advantages of compact structure, beautiful appearance, convenient operation, reliable operation, complete function, convenient repair, strong adaptability, can be stand-alone production also applies to large meat processing production line.

②本機采用進口圓刀，切面光潔，無連刀；刀具設計合理，方便拆卸，易清洗。

The machine adopts imported round knife, cut smooth, without even a knife; tool is reasonable in design, easy disassembly, easy cleaning.

③本機凡與食物接觸部分均采用優質304不銹鋼制造，輸送帶為白色無毒橡膠帶，符合衛生標準，是理想的肉類加工設備。

The machine where the food contact parts are made of high quality 304 stainless steel manufacturing, the conveying belt is a white nontoxic rubber belt, to meet the health standards, is the ideal equipment for meat processing.

備注：1、物料在0-5°狀態下切制效果最大；

Note: 1, the material in the 0-5 degrees state cutting effect is the biggest;

      2、本機可將物料一次性切成規則的條狀，肉條再切便成肉��；

2, the machine can be material one-time cut into regular strips, strips cut it into diced meat;

      3、本機禁止切割帶骨的肉類以及其他的硬物。

3, the prohibition of cutting machine with bone meat and other hard objects.

三、技術參數

Three, the technical parameters

1、肉條機參數

1, strips of machine parameters

①外形尺寸：1700×660×1320 mm（長×寬×高）

The dimensions: 1700 x 660 x 1320 mm (length * width * height)

②入料口尺寸：400×65 mm (寬×高)

The material inlet size: 400 x 65 mm (wide * high)

③輸送帶有效寬度： 400mm

The effective width of conveyer belt: 400mm

④物料切割厚度：0~65mm

The cutting material thickness: 0~65mm

⑤物料切割寬度（兩片刀的刀尖距離）：15mm（標準配置為15mm，也可根據客戶要求定制，0-50mm可選；）

The cutting width (tip distance two pieces of knife): 15mm (standard for the 15mm, can also be customized according to customer requirements, the optional 0-50mm;)

⑥輸送帶電機規格：380V/0.55KW

The conveyor motor specifications: 380V/0.55KW

⑦刀組電機規格：380V/1.5KW

The motor specifications knife group: 380V/1.5KW
